SKU: AL-OTC-SE
ALIS PRO C-Arm Semi Electric Operated | AL-OTC-SE
The C-Arm Semi Electric Operated is a superior Hospital Furniture that provides optimum patient positioning and unobstructed imaging during the surgical process. The C-Arm Semi Electric Operated table has semi-electric height control, manual positioning, radiolucent top, c-arm compatible, stainless steel construction, and easy mobility. This medical furniture ensures perfect stability and comfort of the patient for precise intra-operative imaging. The reliable manufacturer of C-Arm Semi Electric Operated is an expert in manufacturing superior Medical Furniture that complies with the international standards of safety and efficiency in operating theatre performance.
Specifications
Features
Technical Specifications
Positions & Movements
Weight (Approx.)
Standard Accessories
Dimensions (Approx.)
- C-Arm compatible design for imaging procedures
- Semi-electric operation (Height adjustment electric)
- Manual backrest & Trendelenburg positioning
- Heavy duty stainless steel structure
- Radiolucent tabletop for X-ray transparency
- Removable head & leg sections
- Smooth & silent electric actuator
- Hand control panel for height adjustment
- Antibacterial, waterproof mattress
- Stable heavy base for maximum safety
Technical Specifications
- Type: C-Arm Operation Table
- Operation: Electric with Manual Backup
- Control: Handheld Remote Control
- Tabletop: Radiolucent section
- Frame Material: Stainless Steel
- Base Cover: SS / Powder-coated MS
- Power Supply: 220–240V AC, 50 Hz
Positions & Movements
- Trendelenburg: 25°
- Reverse Trendelenburg: 25°
- Lateral Tilt (Left / Right): ±20°
- Back Section Up: 90° ±10°
- Head Section Movement: ±60°
- Leg Section Down: 0° – 90°
Weight (Approx.)
- Net Weight: 280 – 320 kg (Approx.)
- Load Capacity: Up to 250 kg
Standard Accessories
- Padded Shoulder Support – 1 Pair
- Padded Knee Support – 1 Pair
- Anesthesia Screen – 1 Pc
- Arm Rest – 1 Pair
- Crutches with Pad – 1 Pair
- Clamps with Handle – 7 Pcs
- Assembly with Handle – 2 Pcs
- Tray Handle – 1 Pc
Dimensions (Approx.)
- Overall Length: 2000 – 2100 mm
- Width: 480 – 520 mm
- Height Adjustment: 700 – 1000 mm
- Radiolucent Area: Approx. 1200 mm
