ALIS PRO Hematology Analyzer | AL-HA5
SKU: AL-HA5

ALIS PRO Hematology Analyzer | AL-HA5

Hematology Analyzer is a sophisticated piece of Medical Equipment that is used to carry out rapid, accurate, and automated blood tests in hospitals, laboratories, pathology centers, clinics, and medical facilities. This Hematology Analyzer enables accurate testing of the complete blood count (CBC), which includes testing red blood cells (RBC), white blood cells (WBC), platelets, hemoglobin, and other hematological factors. It is equipped with a high-definition touchscreen, automated sample handling, effective data management, and quality control features. A reliable Hematology Analyzer Manufacturer offers superior quality laboratory equipment that conforms to the standards of global healthcare industry.

Specifications

Technical Specifications
Principle
Measurement Method:
  • Electric Impedance Method
  • Colorimetry Method
Parameters
Total Parameters: 21 Reportable Parameters
  • WBC, LYM%, MID%, GRAN%, LYM#, MID#, GRAN#
  • RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD
  • PLT, MPV, PDW, PCT, P-LCR
Histograms: 3 (WBC, RBC, PLT)
Throughput
Sample Throughput: 60 samples per hour
Sample Mode
  • Whole Blood
  • Pre-diluted Blood
Sample Volume
  • ≤ 20 μL
Memory & Storage
  • Data Storage: Up to 1,00,000 results
Display
  • Screen Size: 10.4 inch Touch Screen
  • Display Type: LCD
  • Resolution: 800 × 600
  • Viewing Angle: 10° inclined for visual comfort
Quality Control
  • 3-Level QC (L-J Graph, X-B)
Reagents
  • LH Lyse
  • One Diluent
  • Probe Cleaner (for maintenance)
Flag System
  • RBC, WBC, PLT abnormal sample flags
  • Supports customized test groups
Connectivity
  • 4 × USB Ports
  • 1 × LAN Port
  • HL7 Protocol supported
  • Compatible with LIS system
PERFORMANCE DATA
  • WBC: Precision ≤2.0% (3.5–15.0 ×10⁹/L), Linear Range 0–100 ×10⁹/L, Contamination Rate ≤0.5%
  • RBC: Precision ≤1.5% (3.0–6.0 ×10¹²/L), Linear Range 0–10 ×10¹²/L, Contamination Rate ≤0.5%
  • HGB: Precision ≤1.5% (100–180 g/L), Linear Range 0–250 g/L, Contamination Rate ≤0.6%
  • MCV: Precision ≤1.0% (70–120 fL)
  • PLT: Precision ≤4.0% (150–500 ×10⁹/L), Linear Range 0–1000 ×10⁹/L, Contamination Rate ≤1.0%
Dimensions (Approx.)
  • Width: 390 mm
  • Depth: 285 mm
  • Height: 390 mm
Weight
  • Net Weight: 16 kg
  • Includes histograms, scattergrams & patient information
