SKU: HF-49
Allengers C-Arm Machine New | HF-49
The C-Arm Machine New is one of the most sophisticated Medical Imaging Equipment systems offering real-time high resolution fluoroscopy imaging during orthopedic, cardiovascular, urology, pain management, and general surgeries. The C-Arm Machine New is extensively used in hospitals, operating theaters, trauma centers, and diagnostic centers for precise imaging and image-guided interventions. Being fitted with state-of-the-art digital imaging technology, a high-frequency generator, low radiation output, a simple touch screen display, and easy-to-move c-arm, the machine offers superior imaging and efficiency. A Reliable C-Arm Machine New Manufacturer provides high-quality imaging equipment complying with the health care standards across the globe.
Specifications
Feature
Mechanical Movements
- High Frequency 40 kHz X-ray generator for superior image quality and low radiation dose
- 70–80% higher output with negligible soft radiation (low skin dose)
- Automatic Brightness Stabilizer (ABS) for consistent image clarity
- Self-diagnostic system to reduce service downtime
- Feather-touch microprocessor-based control panel
- Pulse fluoroscopy & High-Definition fluoro mode (optional)
- 64-frame image memory with last image hold & recursive filter
- Compatible with ESWL procedures
- Optional Laser centering device, DAP meter, Iris collimator
- Designed for Ortho, Uro, Gastro, Neuro & Spinal applications
Mechanical Movements
- Vertical Movement of “C”: 430 mm (Motorized)
- Horizontal Movement: 220 mm
- Clearance: 800 mm
- Focus-to-Screen Distance: 950 mm
- C-Arm Rotation: 360°
- Arc Orbital Movement: 90° + 30°
- Wig-Wag (Panning): ±12.5° (25° total)
Approx. Installed Dimensions
- Overall Height Range: 1760 – 2190 mm
- Base Length: ~1774 – 1994 mm
- Base Width: ~700 mm
- Net Weight:
- ~410 kg (Approx.)
Technical Specifications
X-Ray Generator
- Type: High Frequency Generator
- Frequency: 40 kHz
- Max Power Output: 6 kW
- Reproducibility: High, with constant peak waveform
- Fluoroscopy kV: 40 – 120 kV
- Fluoroscopy mA: 0.1 – 5 mA
- Radiographic mA: 30 – 100 mA
- Radiographic Time: 0.1 – 3 seconds
- Fluoro Timer: 5 minutes cumulative
Imaging System
- Image Intensifier: 9” (230 mm), Triple Field (Optional 6” Dual Field / 12” I.I.)
- Grid: 8:1, 100 LPI
- CCD Camera: ½” B/W CCD, CCIR standard (625 lines)
- Standard: 2 × 15”
- Optional: 17” / 19” LCD or CRT
Image Memory Options:
- 64 Frame Memory
- Optional 100 Frame Memory / Digital Image Processor (DIP)
X-Ray Tube
- Type: Monoblock Tube Head
Focal Spots:
- Small: 0.6 mm
- Large: 1.5 mm
- Small: 0.6 mm
- Type: Monoblock Tube Head
- 64 Frame Memory
- Image Intensifier: 9” (230 mm), Triple Field (Optional 6” Dual Field / 12” I.I.)
- Type: High Frequency Generator
- Overall Height Range: 1760 – 2190 mm
