SKU: HF-49
Allengers C-Arm Machine Refurbished | HF-49
C-Arm Machine Refurbished is an advanced imaging machine that has been professionally refurbished and is used to conduct imaging in real time fluoroscopy for operations related to orthopedics, cardiology, urology, pain management, and general surgery. C-Arm Machine Refurbished undergoes intensive inspection and testing to guarantee high levels of efficiency and high quality images in hospitals, operating theaters, trauma centers, and diagnostic clinics. Advanced digital imaging technology, high frequency generator, low radiation level, and easy controls make C-Arm Machine Refurbished a cost-effective imaging machine. A reputable C-Arm Machine Refurbished Supplier offers high quality refurbished imaging machines that adhere to international healthcare standards.
Specifications
Feature
Mechanical Movements
Net Weight:
X-Ray Generator
Type: High Frequency Generator
Frequency: 40 kHz
Max Power Output: 6 kW
Reproducibility: High, with constant peak waveform
Exposure Parameters
- High Frequency 40 kHz X-ray generator for superior image quality and low radiation dose
- 70–80% higher output with negligible soft radiation (low skin dose)
- Automatic Brightness Stabilizer (ABS) for consistent image clarity
- Self-diagnostic system to reduce service downtime
- Feather-touch microprocessor-based control panel
- Pulse fluoroscopy & High-Definition fluoro mode (optional)
- 64-frame image memory with last image hold & recursive filter
- Compatible with ESWL procedures
- Optional Laser centering device, DAP meter, Iris collimator
- Designed for Ortho, Uro, Gastro, Neuro & Spinal applications
Mechanical Movements
- Vertical Movement of “C”: 430 mm (Motorized)
- Horizontal Movement: 220 mm
- Clearance: 800 mm
- Focus-to-Screen Distance: 950 mm
- C-Arm Rotation: 360°
- Arc Orbital Movement: 90° + 30°
- Wig-Wag (Panning): ±12.5° (25° total)
- Approx. Installed Dimensions
- Overall Height Range: 1760 – 2190 mm
- Base Length: ~1774 – 1994 mm
- Base Width: ~700 mm
Net Weight:
- ~410 kg (Approx.)
- Technical Specifications
X-Ray Generator
- Fluoroscopy kV: 40 – 120 kV
- Fluoroscopy mA: 0.1 – 5 mA
- Radiographic mA: 30 – 100 mA
- Radiographic Time: 0.1 – 3 seconds
- Fluoro Timer: 5 minutes cumulative
- Image Intensifier: 9” (230 mm), Triple Field (Optional 6” Dual Field / 12” I.I.)
- Grid: 8:1, 100 LPI
- CCD Camera: ½” B/W CCD, CCIR standard (625 lines)
- Standard: 2 × 15”
- Optional: 17” / 19” LCD or CRT
Image Memory Options:
- 64 Frame Memory
- Optional 100 Frame Memory / Digital Image Processor (DIP)
- Type: Monoblock Tube Head
- Small: 0.6 mm
- Large: 1.5 mm
- 64 Frame Memory
CONTACT US FOR PRICE
