SKU: AL-HE12
ALIS PRO Holter ECG System | AL-HE12
Holter ECG System is an innovative Medical Equipment product used for ambulatory monitoring of the heart. This equipment is utilized in hospitals, cardiology centers, and other healthcare facilities. The Holter ECG System is capable of recording heart activity during 24 to 72 hours and even more, making possible a precise detection of arrhythmias, palpitations, silent ischemia, and other heart disorders during the regular patient's life. This equipment incorporates the advantages of lightweight recording, high-quality ECG, and convenient data analysis. The company known as the trusted Holter ECG System Manufacturer offers a wide range of premium cardiac monitoring devices.
Specifications
Feature
Standard
- With Advance Design And Technology. The Recorder Can Work Stably, Dependable And Durably.
- Be Provided With The Capability Of Anti-jamming And Aseismatic.
- Small Volume With Oiled Screen. The Resolution Is 160#128.
- Be provided with functions of waveform preview, record review and event marketing.
- Accurate record of the start time of the data sampled owing to the real time clock of itself.
- Avoid damage owing to the repeating inserting and pulling out by using the inbuilt TF card to storage the data.
- The maximum capability can be 2gb , so the original data can be saved perfectly by no compression. the average review time of single case can be less than 40 seconds by using interface of USB 2.0.
- Record waveform details intense by the design of high precision sampling frequency.
- Record the state of pacemaker exactly by higher sampling frequency.
- International standard of 12 leads , record 24-hour Drcg with the same standard of the ECG.
Standard
- Number of channel : 12 channel
- Sampling Accuracy : 12bit
- Record Time : 24h
- Power : 2 Aa size Batteries
- Interface : Usb 2.0:
- Scale Voltage : 1 mv+5%
- Standard Sensitivity : 10mm\mv+5%
- Noise level : <30uv:
- Cmrr : >60db:
- Low frequency characteritics Time constanst >3.2s:
- Scan speed : 25mm\s+5%
- Enduring polarization voltage : +300mv Dc polarization voltage, sensitivity shifts<+10%
- Least measuring signal : 50 mvp-p
- Product safety type : Type B (internally powered)
- Dimensions : 111(l)*60(w)*25(h)MM
- Weight : About 105g ( without battery)
