SKU: CMS70A
Contec Table Top Pulse Oximeter | CMS70A
The Table Top Pulse Oximeter is a sophisticated Medical Equipment instrument meant to continuously monitor blood oxygen saturation (SpO2), pulse rate, and perfusion index in hospitals, ICUs, emergency rooms, operation theaters, clinics, and healthcare centers. This Table Top Pulse Oximeter comes with a high definition color screen, audiovisual alarm system, waveform monitoring, rechargeable power supply, and easy to use control mechanisms, which ensure dependable functioning of the instrument for adults, children, and neonates. This sleek and highly accurate instrument comes from a reputed Table Top Pulse Oximeter Manufacturer that offers high quality monitoring instruments that meet international healthcare standards.
Specifications
Feature
Technical Specification
- Low power consumption
- SpO2 value display
- Pulse rate value display, bar graph display
- PI display
- Pulse waveform display
- Menu operation
- Screen brightness can be changed
- The display mode can be changed
- Pulse rate sound indication can be turned on or turned off
- With measured data overruns, limits and low-voltage alarm function, the upper/down alarm range can be adjustable
- Connected with an external oximeter probe
- Data storage function, and the storage data can be uploaded to a computer
- Real-time data can be transmitted to computers
Technical Specification
- Display Mode: TFT Screen and LED display
- Screen Resolution: 320*240
- SpO2 Measuring Range: 0%~100%(the resolution is 1%)
- Accuracy: 70%~100%: ± 2%, Below 70% unspecified.
- PR Measuring Range: 30bpm~250bpm(the resolution is 1bpm)
- Accuracy: ± 2bpm or ± 2% (select larger)
- Measurement Performance in Weak Filling Condition: SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ± 4%, pulse rate error is ± 2 bpm or ± 2% (select larger).
- Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ± 1%.
- Power Consumption: About 350mA
- Voltage: AC 100~240V, 50/60HZ
- Power Supply: Built-in recharge Li-Polymer
- Battery working hour: After the device built-in battery finished the charge, it’s continuous working time is not less than 1 hour
- Safety Type: II device, BF Type
- Dimension : 38L x 25W x 11H cm
- Weight : 1 kg 600 g
